RED-V Things Plus

Overview

The SparkFun RED-V Things Plus is a development board with a SiFive FE310-G002 RISC-V SoC.

For more information about the SparkFun RED-V Things Plus and SiFive FE310-G002:

Hardware

Supported Features

The sparkfun_red_v_things_plus board supports the hardware features listed below.

on-chip / on-board: Feature integrated in the SoC / present on the board.
2 / 2: Number of instances that are enabled / disabled.
Click on the label to see the first instance of this feature in the board/SoC DTS files.
vnd,foo: Compatible string for the Devicetree binding matching the feature.
Click on the link to view the binding documentation.

Programming and debugging

The sparkfun_red_v_things_plus board supports the runners and associated west commands listed below.

	flash	debug

Building

Applications for the sparkfun_red_v_things_plus board configuration can be built as usual (see Building an Application) using the corresponding board name:

west build -b sparkfun_red_v_things_plus

Flashing

The SparkFun RED-V Things Plus uses Segger J-Link OB for flashing and debugging. To flash and debug the board, you’ll need to install the Segger J-Link Software and Documentation Pack and choose version V6.46a or later (Downloads for Windows, Linux, and macOS are available).

With the Segger J-Link Software installed, you can flash the application as usual (see Building an Application and Run an Application for more details):

west build -b sparkfun_red_v_things_plus
west flash

Debugging

Refer to the detailed overview about Application Debugging.
