FocalTech FT9001 Evaluation Board

Overview

The FT9001-EVAL board is an evaluation platform for the FocalTech FT9001 MCU (Arm Cortex-M4F, up to 160 MHz).

Hardware

  • FocalTech FT9001 SoC (ARM Cortex-M4F compatible)

  • 32 KB boot ROM

  • 256 KB on-chip SRAM:

    • 224 KB standard SRAM

    • 32 KB DBUS-connected SRAM

  • 2 MB external flash memory (SPI interface)

  • 2x UART interfaces

  • 2x SPI interfaces

  • External GPIO pins with interrupt capability

Supported Features

The ft9001_eval board supports the hardware features listed below.

on-chip / on-board
Feature integrated in the SoC / present on the board.
2 / 2
Number of instances that are enabled / disabled.
Click on the label to see the first instance of this feature in the board/SoC DTS files.
vnd,foo
Compatible string for the Devicetree binding matching the feature.
Click on the link to view the binding documentation.

Programming and Debugging

The ft9001_eval board supports the runners and associated west commands listed below.

flash debug

Flashing

Build and flash the Hello World sample application:

west build -b ft9001_eval samples/hello_world
west flash
